JS-F20

    • 20W fiber laser marking machine
  • JS-F20

    20W fiber laser marking machine

    • Permanent marking
    • Flexible, dynamic data can be marked
    • Cost-efficient production
    • Laser marking in seconds for more throughput
    • Perfect marking results - fine tool
    • Integration into production lines
    • Non-contact and process-safe
    • Working life (50000-100000 hours)
    • Maintenance-free
    • Low energy consumption, ( 0.8 kilowatt-hour/hour)
    • Engraving precision of character ( min 0.2mm)
    • High speed

    20W fiber laser marking machine

    Product Description


    JS-F series standard fiber laser marking machine is a high-quality,high-performance machine.It is equipped with core optical devices such as well-known brand fiber lasers and scanning galvanometers to improve the performance and stability of the product.The self-developed all-digital high-speed marking control card and powerful software can meet the high-precision marking and marking requirements of different industries.


    JOY STAR LASER’s main products include CO2 laser marking machine, fiber laser marking machine, ultraviolet laser marking machine, CO2 laser cutting machine, fiber laser cutting machine, laser welding machine, non-standard automation and many other series. Our laser device is used in more than 100 professional fields around the world, and it is our service tenet to provide customers with the best intelligent laser application solutions.


    Product parts advantages


    fiber laser marking machine structure

    fiber laser marking machine Optional device.jpg


    Optional


    1. Rotary device and platforms (Optional);

    It can be equipped with rotary device, it can be rotated 360° and is suitable for processing applications in various scenarios.


    2. Rotary chuck;


    3. 2D / 3D table and extended platform;


    4. Visual marking system;


    Fiber laser adopts high-quality laser source, good spot quality, uniform optical power density, stable output optical power, no laser leakage, anti-high reflectivity, etc., meeting mainstream market application requirements


    Self-owned brand digital high-speed scanning head, small size, fast speed, good stability, performance reaches the international advanced level;


    The control system is powerful, capable of optimizing various data according to different processes, supporting one-key switching of multiple languages, supporting up to 256 color layer management and other functions, meeting the application process requirements of most industries in the market;



    Laser marking samples

    Open mold die-casting manufacturing lifting frame, built-in linear guide rail, stable structure, simple design.


    Using the most advanced laser generator in the industry, the spot is good, the performance is strong and stable, and the laser generator life is up to 100,000 hours.


    Cooperate with high-speed galvanometer scanning system, fast speed, strong anti-interference ability and high marking accuracy.


    Integrated design, beautiful appearance, firm structure, simple operation, no consumables, and maintenance-free.


    Non-contact processing, no damage to the product, no tool wear, exquisite marking, never fade.


    The machine is no pollution, no noise, and can work continuously for 24 hours.


    Smaller size, saving space.


    The software can support DXF PLT BMF AI JPG and other formats.


    The software is compatible with batch import of TxT Excel and other content, making marking easier.


    The software can automatically generate serial number, production date, QR code and barcode.


    Applicable materials and industries:


    Hardware industry:

    All metals, all alloys, molds (which can be processed deeply, the depth can reach 0.5mm), glasses and watches, jewelry, hardware tools, aluminum oxide mark black, machine nameplates.


    304 stainless steel, titanium alloy can be processed in color (commonly used: white, black) (not commonly used: red, yellow, green, pink, purple, gray, blue,).


    Electric industry:

    Electroplating materials, (TPU mobile phone cases, hardware, plastics, etc.), spraying materials (oil-injected light-transmitting buttons, silicone oil-injecting light-transmitting), plastic rubber, integrated circuit (IC) epoxy resin, insulating tape, circuit boards, electronic components Devices, aluminum oxide mark black, mobile phone shells, chargers and other plastic shells, PC plastic, PPT plastic, and some ABS materials.


    Packaging industry:

    Colored packaging carton (with color area on the outer packaging of energy-saving lamps).


    Qualification honor


    Joy Star Laser Qualification honor

    FAQ


    ✦How to get the most suitable machine and best price?

    Please tell us the material you want to working on ? How to working on it ? Engraving ? Cutting ? Or other ? Mainly engraving or cutting?

    What’s the MAX size of these material ?( length ? Width ? Thickness ?)


    ✦How to operate the machine ?

    We will deliver English manual and video with the machine to you. If you still need our help, please contact us.


    ✦How we pay you ?

    Please contact us, after confirm machine and optional parts to order, we will give you the link to order.


    ✦How can I get the sample to check you quality ?

    If you want to marking sample to check the quality, we can help you do this. first you need to provide the logo or design to us, free mark samples can be provided.


    ✦Does the machine can be customized according to my requirements ?

    Sure, we have a strong technical team and have rich experience. Our goal is to make you satisfied.


    ✦Can you arrange the shipment for me ?

    We can arrange the shipment for our clients by sea or by air. Trading terms FOB, CIF, EXW are available.


    ✦How about your after-sales service?

    we offer you 24 hours service phone, Email or Whatapp.


    ✦Quality Control:

    The whole production procedure will be under regular inspection and strict quality control.

    The complete machine will be tested to make sure they can work very well before being out of factory.

    Our machine passed CE Certificate, meet European and American standard, were exported to more than 100 Countries.


    ✦How we can  contact you ?

    you just need to leave your contact information,like email , whatsapp on our website , we will contact you asap .


    If you interest in this machine,pls feel free to contact me to get more informations.



    stainless steel, alloyed steels

    aluminum, anodized aluminum

    titanium, titanium alloys

    brass

    copper, other precious metals

    coated metals

    PA, PC, PE, PET, PMMA

    silicone or many other plastics


    MODELJS-F20
    Processing Area(mm)150mm×150mm
    Laser power

    ≤20W

    Laser tube typeFiber laser
    FunctionLaser Marking
    Gross Power≈1000W
    Measurement (L×W×H)900mm×620mm×1100mm
    Cooling typeAir cooling
    Weight150KG
    Power Supply220V/10Amax, 50Hz or 60Hz
    Environmental requirementsTemperature: 10-30℃Humidity:  no condensation 30-80%
    System/compatible  FormatWindows 7/8/10,AI , PLT , DXF , DST ,BMP , JPG , JPEG ,PNA , TIF


    JS-F20
